ODM600 Series

The ODM600 vertical packaging machine, which can be manufactured with pneumatic and servo-controlled systems, is specially designed for high-weight product packaging. Depending on the product type and weight, it can reach operating speeds of up to 80 packs per minute.

The system forms pillow bags, stand-up pouches, and quadro bags from roll stock film and, when integrated with product-specific dosing units, enables precise filling within a range of 500–5000 g.

Pouch Shapes

The ODM600 Series vertical packaging machines are designed to operate with pillow bags, stand-up pouches, and quadro bags. Offering flexible changeover between different bag types, they ensure high efficiency across a wide range of products.

Products

BROCHURE
VIDEO

Optional Applications

Optional features available for ODM Series Vertical Packaging Machines:

  • Metal detection and foreign body inspection systems with automatic rejection (before and after filling)
  • Modified Atmosphere Packaging (MAP) gas flushing systems
  • In-pack gas ratio control systems
  • Printing systems for production date, expiry date, batch number, barcode, etc.
  • Automatic checkweigher systems with reject function after packaging
  • Platform-mounted weighing bucket washing unit
  • Label printing and application systems
  • Euro hole (hang hole) and handle hole applications
  • Front strip application systems on packages
  • Promotional item (tazo) feeding systems
  • Static electricity elimination systems
  • Dust extraction systems

Features & Advantages

  • Fully automatic operation reduces labor costs
  • Optimizes packaging material consumption
  • User-friendly operation via PLC-HMI interface
  • Fast changeover between different products and weights with recipe system
  • Easy integration with production and case packing lines
  • Designed in compliance with CE standards and occupational safety requirements
  • Fully automatic film centering system
  • Audible and visual low film warning system for maximum efficiency
  • Automatic film catching at reel end for quick and easy reel change
  • Suitable for both photocell and non-photocell operation
  • Level-controlled feeding systems for accurate and stable filling
  • Easy integration with product protection systems
  • Communication capability with SAP and other production tracking systems
  • Remote access and communication system for fast service and troubleshooting
